Batteries in automotive applications must be continuously monitored to make sure that the battery is in a healthy state.
Optical Interface 50Mbit/s for NI FlexRIO
Optical interface 50Mbit/s for NI FlexRIO platform including 4 Transmitters and 4 Receivers.
Battery Management & Junction Box Validation
Test of battery power distribution units with high voltage and high current, optionally including onboard chargers and DC/DC converters and battery cell management.
Simulation of electrical machines for inverter lifetime-, end-of-life- and system-tests.
Pulse Current System up to 35kA
The testing of safety elements under short-circuit conditions is an important safety aspect in the development of new electric vehicles.
SDR Condition Monitoring
High speed characterization using resonance effects of antennas with software defined radio.
Software tool for statistical analysis of test results and measurement systems analysis (MSA).
AC current stress in lifetime test of DC-Link capacitors including precise component characterization.
Positioning and Power Tests
Positioning and power tests while applying different temperature setups.
TUI (TestStand User Interface)
IRS Modular TestStand User Interface is a custom user interface for executing test sequences created for National Instruments TestStand. It acts as a front-end for the TestStand API, which is executing the sequences.
CAN-FD/LIN Interface Card
This interface card provides 6 CAN-FD channels and 12 LIN channels.
IRS SSV products provide high speed, gapless and autonomous real time signal analysis and supervision for periodic signals.
IRS MesSy II (FD)
Combines high quality measurement technology and pure computing power through the combination of microcontroller and FPGA technology.
The IRS Universal Contacting Multiplexer (UniCoMux) is a stand-alone system that can be used to establish an electrical connection between the system input and one of several outputs.
cRIO Resolver Simulation
IRS cRIO resolver simulator can be used in a National Instruments Compact-RIO chassis to simulate the signal of the resolver sensor of electric motors.
cRIO OPIF 10MBit/s
Compact-RIO Optical Interface module for fibre communication – 3-fold 10MBit/s (Versatile Link).
cRIO OPIF 20MBit/s
Compact-RIO Optical Interface module for fiber communication 2x 2-fold 20MBit/s.
ValDi & ValDino
Our valve control driver and unit is a piece of hardware for automotive solenoid valves for test purposes.
High-power DC & pulsed current source for LED testing.
FlexRIO Fiber Optic Module
Test of Fiber optical communication interfaces based on NI FlexRIO.
Current Measurement Module
Current measurement module may be used for monitoring both quiescent and operating current consumption of automotive electronic control units.
FSB – Fault Simulation Box
A fault simulation box enables to simulate short circuits up to 30A between signals.
FlexRIO Ethernet Interface
Recording of Ethernet communication including detection of precise time stamps with a resolution of 20ns.
